Shimano 12 Speed M6220 Deore Crank - Direct Mount | 1x12-speed FC-M6200 Crankset
Shimano 12 Speed M6220 Deore Crank - Direct Mount | 1x12-speed FC-M6200 Crankset
⚠️❗️NOTE❗️⚠️ No Retail Packaging
Deore M6200/M7200 – Simplicity Without Worry.
Designed for riders who value fast shifting, consistent braking performance and durability—and who, above all, appreciate mechanical simplicity. Visually, the M6200 and M7200 components are inspired by the elegant design of the electronic Deore Di2 series. Also technically the mechanical 12-speed components match the performance of their electronic counterparts, making them a viable upgrade option for all MTB disciplines.
Shimano Deore FC-M6200 crankset
Peak Pedal Power. With its two-piece construction, rigid steel crankshaft and optimized Q-factor, the crank from the Deore M6200 series by Shimano ensures reliable power transfer. Equipped with the Dynamic Chain Engagement+ technology, the chainring further increases drivetrain efficiency and also improves the chain retention on rough terrain. All components share not only exceptional stiffness and durability but also a clean design.
2-Piece Crankset | The two-piece construction, in which the right-hand crank arm is firmly connected to the shaft of the bottom bracket, serves to optimize the ratio between stiffness and low weight. In combination with the external bearing, which also results in an increased bottom bracket distance, the power transmission is noticeably improved.
Dynamic Chain Engagement+ | The special tooth profile was developed for use in single-chainring configurations in XC, Enduro and Trail Riding. It ensures improved chain guidance, resulting in a smoother pedaling experience, even on uneven terrain. The chain retention provided by each individual tooth reduces wear on the entire profile.
Technical Details:
Crank arms: aluminum (anodized)
Chainring: steel (painted)
Crankshaft: steel (plated)
Chainring interface: Direct Mount
Chain line: 55 mm
Q-factor: 176 mm
Compatibility:
Chain: CN-M9100, CN-M8100, CN-M7100, CN-M6100
Bottom bracket (thread type): BB-MT501, BB-MT500, BB-MT801, BB-MT800, SM-BB93, SM-BB80, SM-BB52
Bottom bracket (Press Fit): BB-MT500-PA, BB-MT800-PA, SM-BB94-41A
Rear wheel (over locknut dimension): 148 mm (thru axle, Boost)
Dcbikes Product Features :
Product Name: Shimano Deore FC-M6200 Crankset - Direct Mount | 1x12-speed
Manufacturer: Shimano Parts
Activity: Cycling
Material: Aluminium, Steel
Usage bikesport: MTB
Number of gears - Front: 1
Number of Gears - Rear: 12
Bottom bracket axle Profile: 24mm Hollow Shaft
Direct mount Standard: Shimano MTB
Chainring version: Narrow-Wide, for 1/8" Chains, round
Chainring mount: Direct Mount
Chain line: 55mm
Q-factor: 176 mm
Color: Black
Weight : 730g
Package Includes :
1 X New Deore M6220 Crank
⚠️❗️NOTE❗️⚠️ No Retail Packaging
